Development Of An Unmanned Underwater Remotely Operated Crawler (ROC) Based On Wheel Mechanism

Mohd Zainal, Muhammad Iktisyam (2015) Development Of An Unmanned Underwater Remotely Operated Crawler (ROC) Based On Wheel Mechanism. Project Report. UTeM, Melaka, Malaysia. (Submitted)

Text Development Of An Unmanned Underwater Remotely Operated Crawler (ROC) Based On Wheel Mechanism 24 Pages.pdf - Submitted Version Download (524kB)

Abstract

Underwater vehicles are a type of vehicle that a type of vehicles that able to explore the underwater world. Remotely Operated Crawler (ROC) is one of the Unmanned Underwater Vehicle (UUV) that can be categorized in Remotely Operated Vehicle (ROV) class. The specialty of ROC allows for underwater intervention by staying a direct contact with the seabed. The common issues face for the crawlers are the underwater pressure, manoeuvrability, power and control. Besides that, the surface of the seabed become one of the problems in that restrict on ROC maneuverability. Designing a ROC that can crawl in any surface conditions is one of the issues emerged in this project. This project is about developing such ROC in order to fulfil a specific mission involving certain tasks. ROC lend themselves to long-term work and offer a very stable platform for manipulating objects and taking measurements better than other ROV. SolidWork is used as the software and platform in designing the crawler. Simulation test is done using application available in the software which is the SimulationXpress. Development an ROC based on wheel mechanism that allows the ROC moves with direct contact with the seabed without any glitch and have an ability to operate in any condition of the underwater environment. The wheel mechanism is adapted based on the tanks which is the chain type wheels. The performance of the ROC will be verified based on experiments conducted on the cluttered condition either on the surface or underwater. The ROC is capable to climb an obstacle of the maximum height of 9.5 cm. The operation of ROC can achieve excellent performance with an unexpected level of environmental condition.
