Improve Of Design And Analysis Of Hydraulic House Fence Opening Using Tap Water Pressure

Ayop Azmi, Faiz Aswad (2017) Improve Of Design And Analysis Of Hydraulic House Fence Opening Using Tap Water Pressure. Project Report. UTeM, Melaka, Malaysia. (Submitted)

Text (24 Pages) Improve Of Design And Analysis Of Hydraulic House Fence Opening Using Tap Water Pressure.pdf - Submitted Version Download (570kB)

Abstract

This thesis discussed the improvement of design and analysis of house fence opening. The objectives of this thesis are to improve the design for existing hydraulic fence product, to fabricate the prototype, and to analyze and compare the capability of the improvement product. The main problem of existing product made is the cost and the previous researcher does not use automatic system to operate the fence movement. The cost can be divided into two categories, which is manufacturing cost and operating cost. The existing product need to operate using variety of manual valve. Next, method that have been used to solve this problem is started with finding all related information about the fence opening system. The information is taken from internet, books, journals, newspapers and thesis. Then, the House of Quality was used to identify the characteristic that need to improve and listed the specification in product design specification. In conceptual design, the process start with morphological chart to provide the analytical and systematic concepts. Five concept design was generated based on product design specification and one best concept have been choose using Pugh method. Concept 4 was selected based on reliability, cost and ease of replacement of the components. The selected design was simulated using FluidSIM software and the simulation works correctly according to design. From the result, the prototype was working and the system was controlled using automatic remote control to open and close the fence. The system operates with 30 kg fence with pressure of 33 psi.
